Portable ultrasound machine veterinary

Description

Portable ultrasound machine veterinary MSLVU31

Quick Details

Dog ultrasound machine

Specifications

Probe: 3.5C8050L Convex Probe

Detection depth: ≥140mm

Dead zone: ≤3 mm

Resolution: Horizontal:≤2 mm（Depth≤80mm）

:Vertical: ≤1mm（Depth≤80mm）

Geometric location accuracy: Horizontal:≤10%

:Vertical: ≤5%

Amplification factor: 1.0, 1.2, 1.5,2.0

Scanning manner: Electronic convex array

Working frequency: 2.5MHz~5MHz

Display mode: B, B+B

Scanning range: Convex array 50°

Image gray-scale: 256 levels

Scanning line number: 512 lines/frame

Frame rate: 30 frames/second

Digital scanning conversion: 512×512×8 bits

Display screen: 5 "-TFT

Overall size: 228mm×143mm×30mm

Total weight: 840g

Battery capacity: 3000mAH/7.4V

Continuous work: Over 2 hours

Power consumption: 7W

Storage: ＞2G U flash Disk

Portable ultrasound machine veterinary MSLVU31 Specification

Sconning Mode: Electronlc Convex.

standard conflguration: 3.5MHz Convex probe

Screen size: 5 inch TFTLCD

Display Mode: B, B+B

Frequency: 2.5/3.5/5.0MH2

Depth: Max 190mm

Weight: 850g (Battery included)

Continuous working time: 22 hours

Ilmoge storage: 28 G U-Disk

Battery Copocity: 3000mAH/7.4V

Port: Video, USB2.0

Brightness IControction: Adjustable

Near 1 Middle 1 For goin: Adjustable

Measurement: Distance. Perimeter. Area, Volume

Application: Sow, Sheep, Goat. Apaco

Warranty: Mainunit for 18 months and 12 months tor probes
