Color Doppler Ultrasound Machine

Description

Hand Carried Color Doppler Ultrasound Machine For Vet MSLVU41

Quick Details

physical spec:
System Dimension:
Height: 402mm Width: 385mm Depth: 98mm

Weight:    Around 6.2 kg (Include Battery)

Physical channels:    64

Specifications

Hand Carried Color Doppler Ultrasound Machine For Vet MSLVU41

physical spec:
System Dimension:
Height: 402mm Width: 385mm Depth: 98mm

Weight:    Around 6.2 kg (Include Battery)

Physical channels:    64

Transducer element: 128

Monitor:
 15'' high resolution LCD monitor with tilting to view it freely and comfortably
Resolution: 1024×768
Brightness Adjustable
Max Opening Angle: 45°

Materials of systems:
Fireproofing and anti‐corrosion ABS

Power:    System operates via AC power & battery

AC Adapter:
Model: MANGO‐BMV‐15AD‐C5
Voltage: 100‐240VAC
Frequency: 50/60 Hz
Currency: 5A
Output: 15V

Battery: (optional)
Model: LY606090
Lithium‐Ion, 11.1V , 8000mAH
Charge to Full: 6 hours
Max Duration: 120 minutes realtime scan *
vary on the configuration and different working condition, for more details to contact the sales.

Operating Evironment:
Temperature: 0‐40 °C
Humidity: 30%‐85% (non‐condensing)
Pressure: 700hPa‐1060hPa
Storage and Transport:
Temperature: ‐20‐55 °C
Humidity: 30%‐95%(non‐condensing)
Pressure: 700hPa‐1060hPa
